TAPC - 2C
The Texmo TAPC-2C is the most advanced model in the automatic pressure controller range — featuring a user-adjustable starting…
description Overview
The Texmo TAPC-2C is the most advanced model in the automatic pressure controller range — featuring a user-adjustable starting pressure from 1.0 to 3.5 bar, giving you precise control over when your pump activates. This makes it ideal for high-performance water systems where the fixed presets of other controllers are not sufficient.
Built for maximum pump power (up to 2.2 kW / 30A) with an R2" connection for larger pipe systems, the TAPC-2C suits commercial buildings, agricultural pump stations, and industrial water distribution networks. It operates on 220V–240V single-phase power and includes full automatic start/stop and dry-run protection as standard.
check_circle Key Features
- User-adjustable starting pressure (1.0–3.5 bar) — set the exact trigger point to match your system requirements
- Handles pumps up to 2.2 kW / 30A — the highest power rating in the Texmo pressure controller range
- R2" large-bore connection thread designed for commercial and agricultural pipe systems with higher flow demands
- Fully automatic pump start/stop based on flow detection — no pressure tank, no manual switching required
- Built-in dry-run protection stops the pump immediately if water supply is interrupted
- 220V–240V single-phase rated with IP65 waterproof and dustproof casing for long-term outdoor installation
handyman Applications
- Automatic pump control for domestic water supply
- Maintaining constant water pressure in homes and apartments
- Garden and lawn irrigation systems
- Pressure boosting for multi-story buildings
- Small commercial and light industrial water systems
- Protecting pumps from dry running damage
settings Technical Specifications
